Maximum push and pull force off 400N. Thanks to the synchronization function
it is possible to obtain a total maximum force up to 2240N.
Synchronization of multiple actuators, parameter adjustment, recording
and diagnostics in real time by simply scanning the QR code. The die-cast aluminum casing and brackets guarantee high resistance even in particularly difficult environments. The actuator has passed the heat resistance tests required by the EN12101-2 standard.
The high quality and sturdiness of the double link stainless steel chain guarantee
the transmission of the maximum force both in traction and in thrust. Maximum
stroke length 500mm.
The new wi-fi technology, in addition to giving the possibility of making very precise adjustments using the Mowin App, allows synchronization of up to 8
LIWIN L40 for the possible installation of several actuators in a single window or on systems where a force is required elevated.
The Mowin App allows both the recording of the last maneuvers with any reported anomalies and real time diagnostics to identify and malfunction errors. The actuator is also equipped with a led able to signal if there are any anomalies.
All our products are despatched within 3 working days
All items are supplied with a 12-month warranty period. We are unable to accept items back for any reason after the warranty has expired.
